Name: The Role of Legal Metrology in Modern Weighing Inspection Systems
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Modern Weighing Inspection Systems
Availability: InStock

Casa Prodotti Automatic Checkweigher

The Role of Legal Metrology in Modern Weighing Inspection Systems

Dettagli:

Place of Origin:	CHINA
Model Number:	Modern Weighing Inspection Systems

Termini di pagamento e spedizione:

Minimum Order Quantity:	1 set
Prezzo:	Negoziabile
Packaging Details:	Caron box
Delivery Time:	10-30days
Supply Ability:	2000 set per month

Contatto

Descrizione di prodotto dettagliata

Product:	The Role of Legal Metrology in Modern Weighing Inspection Systems	Capacity Range:	1g-150kg
Verification Scale Interval (e):	0.1g-10g	Number of Scale Intervals (n):	3,000-10,000
Repeatability:	≤1.0e	Temperature Range:	0°C to 40°C
Humidity Range:	15% to 85% RH	Vibration Resistance:	≤0.2g RMS
NTEP Class:	III	OIML Approval:	Y(b)
MID Compliance:	Class III	Measurement Canada:	S.8
Evidenziare:	legal metrology weighing systems , automatic checking weigher inspection , modern weighing inspection technology

The Role of Legal Metrology in Modern Weighing Inspection Systems

Introduction to Legal Metrology in Industrial Weighing

Legal metrology forms the foundation of trustworthy weighing inspection systems in modern manufacturing and trade environments. As global supply chains become more complex and regulatory requirements more stringent, the integration of legal metrology principles into weighing systems has evolved from simple compliance to a strategic quality assurance imperative.

Core Principles of Legal Metrology in Weighing

1. Metrological Traceability

Definition: Unbroken chain of calibrations to national/international standards
Implementation:
- NIST (USA), PTB (Germany), or NIM (China) traceable certification
- ISO/IEC 17025 accredited calibration procedures
- Documentation of measurement uncertainty budgets

Industry-Specific Implementations

Pharmaceutical Manufacturing

Critical Parameters:
- USP <41> compliance for balances
- 21 CFR Part 11 electronic records
- Measurement uncertainty ≤0.1% of tolerance
Validation Protocol:
- 3-point calibration (min, nominal, max)
- 99.7% confidence level (3σ)

Retail Weighing Systems

Key Requirements:
- Automatic price calculation verification
- Zero-tracking within ±0.25e
- Mandatory sticker printing accuracy
Inspection Frequency:
- Initial verification
- Annual surveillance
- 2-year recertification

Parameter	Specifications
Capacity Range	1g-150kg
Verification Scale Interval (e)	0.1g-10g
Number of Scale Intervals (n)	3,000-10,000
Repeatability	≤1.0e
Temperature Range	0°C to 40°C
Humidity Range	15% to 85% RH
Vibration Resistance	≤0.2g RMS
NTEP Class	III
OIML Approval	Y(b)
MID Compliance	Class III
Measurement Canada	S.8
