The Ultimate Guide to Choosing the Right Check Scale

Dettagli:

Luogo di origine:	CINA
Numero di modello:	La guida definitiva per scegliere la giusta bilancia

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 set
Prezzo:	Negoziabile
Imballaggi particolari:	Caron Box
Tempi di consegna:	10-30 giorni
Capacità di alimentazione:	2000 set al mese

Contatto

Descrizione di prodotto dettagliata

Prodotto:	La guida definitiva per scegliere la giusta bilancia	Capacità massima:	3 kg, 15 kg, 60 kg, 300 kg
Leggibilità / Graduazione (d):	0,1 g, 1 g, 5 g, 50 g	Capacità minima:	Tipicamente 10 volte la leggibilità.
Classe di precisione:	Classe I, II, III, IIIII	Certificazione:	NTEP (U.S.), OIML (International), CE
Dimensione della piattaforma:	250x300 mm, 400x500 mm, 600x800 mm	Materiale della piattaforma:	Acciaio inossidabile, acciaio mite, plastica ABS
Tipo di visualizzazione:	Display LCD (Liquid Crystal Display), LED (Light Emitting Diode)	Classificazione IP (Protezione contro l'ingresso):	IP65, IP67, IP68
Alimentazione elettrica:	Adapter CA, batteria ricaricabile, celle secche
Evidenziare:	check weighing for food industry , pharmaceutical check weighing scales , Mettler Toledo load cell scales

The Ultimate Guide to Choosing the Right Check Scale

A check scale (also known as a weighing scale) is a vital piece of equipment for many industries, from logistics and manufacturing to retail and agriculture. Choosing the right one ensures accurate measurements, improved efficiency, and compliance with regulations. This guide will walk you through the essential factors to consider and provide a detailed parameter table to help you make an informed decision.

Key Factors to Consider

1. Capacity and Readability:

Capacity: This is the maximum weight the scale can handle. It's crucial to choose a scale with a capacity greater than the heaviest item you'll be weighing. Overloading a scale can damage it and lead to inaccurate readings.
Readability (or Graduation): This is the smallest increment the scale can measure. For example, a scale with a readability of 1g can display weight in 1-gram increments. High readability is essential for weighing small, precise items, while lower readability is acceptable for heavier, less critical items.

2. Accuracy and Legal-for-Trade Certification:

Accuracy: This refers to how close the scale's measurement is to the true weight of the item. All scales have a degree of error, and a good quality scale will have a low margin of error.
Legal-for-Trade: If you're using the scale for commercial purposes where the weight determines the price of a product (e.g., selling produce, shipping packages), the scale must be "legal-for-trade" or "NTEP certified" (in the U.S.). These certifications ensure the scale meets specific government standards for accuracy and reliability.

3. Platform Size and Construction:

Platform Size: The size of the weighing platform should be large enough to comfortably hold your typical items without obstructing the display or controls.
Construction Material: Scales are typically made from stainless steel, mild steel, or plastic. Stainless steel is durable, corrosion-resistant, and easy to clean, making it ideal for food processing or harsh environments. Mild steel is a cost-effective option, often used in dry warehouses. Plastic is lightweight and suitable for light-duty applications.

4. Environment and Durability (IP Rating):

Environment: Consider where the scale will be used. Will it be exposed to dust, water, or extreme temperatures?
IP (Ingress Protection) Rating: This rating indicates how well the scale is protected against solids and liquids. For example, an IP65 rating means the scale is dust-tight and protected against water jets. An IP68 rating means it's fully protected against dust and can be submerged in water.

5. Connectivity and Features:

Connectivity: Modern scales often come with various connectivity options, such as USB, RS-232, Ethernet, or Wi-Fi. This allows the scale to interface with computers, printers, and other systems.
Features: Look for features that will improve your workflow, such as tare function, counting function, checkweighing, backlit display, and battery operation.

Specifications

Parameter	Specifications
Maximum Capacity	3 kg, 15 kg, 60 kg, 300 kg
Readability / Graduation (d)	0.1 g, 1 g, 5 g, 50 g
Minimum Capacity	Typically 10x the readability.
Accuracy Class	Class I, II, III, IIII
Certification	NTEP (U.S.), OIML (International), CE
Platform Size	250x300 mm, 400x500 mm, 600x800 mm
Platform Material	Stainless Steel, Mild Steel, ABS Plastic
Display Type	LCD (Liquid Crystal Display), LED (Light Emitting Diode)
IP Rating (Ingress Protection)	IP65, IP67, IP68
Operating Temperature	-10°C to +40°C
Interfaces/Connectivity	RS-232, USB, Ethernet, Bluetooth, Wi-Fi
Weighing Functions	Tare, Counting, Checkweighing, Accumulation
Stabilization Time	1-3 seconds
