Name: Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Cella di carico MT1241-150kg 2m
Availability: InStock

Casa Prodotti

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

Dettagli:

Luogo di origine:	CINESE
Marca:	Mettler Toledo
Numero di modello:	Cella di carico MT1241-150kg 2m

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 set
Prezzo:	Negoziabile
Imballaggi particolari:	Scatola di carone
Tempi di consegna:	10-30days
Capacità di alimentazione:	2000 set al mese

Contatto

Descrizione di prodotto dettagliata

Prodotto:	Cella di carico Mettler Toledo	Capacità massima:	330 libbre (150 kg)
Materiale:	di alluminio, passivato	Metrologia:	NTEP III 5.000d OIML C3
Accuratezza:	Norme	Grado di protezione:	IP67
Dimensione piattaforma (Lu x La):	400 mm x 400 mm	Connettività:	Analoghi
Cavo:	6.6 ft (2 m)
Evidenziare:	MT1241 load cell sensor 150kg , industrial grade weighing sensor , load cell with 2m wire

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

High-Performance Compression Weigh Module

This compression weigh module features top and base plates that compress under load, designed for direct installation on ground, piers, or structural beams. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications.

Key Features

High-performance single point load cell with off-center compensation
Standard metrology approvals including OIML
Premium aluminum construction with strain gauge technology for durability
ATEX Zone 1/21/2/22 approvals included as standard
IP67 protection rating for harsh environments

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	330 lb (150 kg)
Material	Aluminum, passivated
Material Number	71201841
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	6.6 ft (2 m) PVC

Ideal Applications

Perfect for mid-size platform scales in industrial environments. The robust design and hazardous area certifications make it suitable for demanding weighing applications in manufacturing, logistics, and process industries.
