Name: SLP332D-IOL Load Cell – 50kg C6/9k IO-Link Digital Weighing Sensor
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Cella di carico SLP332D-IOL-50kg C6/9k
Availability: InStock

Casa Prodotti

SLP332D-IOL Load Cell – 50kg C6/9k IO-Link Digital Weighing Sensor

Dettagli:

Luogo di origine:	Cina
Marca:	Mettler Toledo
Numero di modello:	Cella di carico SLP332D-IOL-50kg C6/9k

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 Set
Prezzo:	Negoziabile
Imballaggi particolari:	Scatola di carone
Tempi di consegna:	10-30days
Capacità di alimentazione:	2000 set al mese

Contatto

Descrizione di prodotto dettagliata

Prodotto:	Cella di carico Mettler Toledo	Capacità massima:	50 kg (110 lb)
Materiale:	di alluminio, passivato	metrologia:	NTEP III 5.000d OIML C3
Precisione:	standard	Grado di protezione:	IP67
Approvazione pericolosa:	ATEX, FM	Criticità:	Standard
Dimensione della piattaforma (LxW):	400 mm x 400 mm	Connettività:	Integrato
Evidenziare:	50kg digital load cell , IO-Link weighing sensor , Mettler Toledo load cell

SLP332D-IOL Load Cell – 50kg C6/9k IO-Link Digital Weighing Sensor

Key Features:

Direct PLC connectivity via IO-Link interface
Quick installation with standard cables and connectors
Smart5™ alarms and condition monitoring
Factory calibrated for immediate startup

Product Description

The SLP332D-IOL is a compression weigh module designed for industrial weighing applications. When weight is applied, the top plate and base plate compress together, allowing direct attachment to ground, piers, or structural beams. Ideal for use in multiple configurations under large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing systems.

Attribute	Specification
Maximum Capacity	110 lb (50 kg)
Material	Aluminum, passivated
Metrology Certification	NTEP III 5,000d OIML C3
Protection Rating	IP67
Hazardous Area Approval	ATEX, FM
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Integrated IO-Link

Technical Advantages

Integrated PLC connectivity: Direct connection to automation systems without additional electronic units
Smart5™ technology: Continuous condition monitoring with NAMUR NE 107 alarms for increased machine uptime
Robust construction: Aluminum passivated material with IP67 protection for harsh environments
Precision measurement: High accuracy with NTEP III and OIML C3 certifications
