Name: SWC515-A CS 30t Weigh Module - Heavy-Duty Carbon Steel Load Cell for Tanks and Silos
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Modulo di pesatura SWC515-A CS 30t
Availability: InStock

Casa Prodotti

SWC515-A CS 30t Weigh Module - Heavy-Duty Carbon Steel Load Cell for Tanks and Silos

Dettagli:

Luogo di origine:	CINESE
Marca:	Mettler Toledo
Numero di modello:	Modulo di pesatura SWC515-A CS 30t

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 SET
Prezzo:	Negoziabile
Imballaggi particolari:	Scatola di carone
Tempi di consegna:	10-30days
Capacità di alimentazione:	2000 messo al mese

Contatto

Descrizione di prodotto dettagliata

Prodotto:	Cella di carico Mettler Toledo	Capacità massima:	66,000 lb (30.000 kg)
Materiale:	Zinchi l'acciaio placcato	metrologia:	OIML C3, NTEP IIIL 10,000
Cella di carico:	0782/GD, cavo di 13 m	Precisione:	standard
Classificazione di protezione:	IP68/69k	Ambiente / Materiale:	Acciaio normale / acciaio al carbonio
Approvazione pericolosa:	ATEX, FM	Criticità:	standard
Evidenziare:	heavy-duty carbon steel load cell , CS 30t weigh module , load cell for tanks silos

SWC515-A CS 30t Weigh Module - Heavy-Duty Carbon Steel Load Cell for Tanks and Silos

Product Overview

A compression weigh module designed so that its top plate and base plate will be squeezed toward each other when weight is applied. It can be attached directly to the ground, piers or structural beams. Compression weigh modules are typically used in multiples under large platform scales such as truck and railroad track scales and in tank, hopper and silo weighing.

Key Features

Multi-Purpose: Suitable for static & dynamic tanks, hoppers, mixers & conveyors with high accuracy fully approved stainless hermetic load cell
Enhanced Safety: Mechanical safety features (360° self-checking, lift-off & down-stops protections), hazardous approvals & IP68 load cells
Easy Installation: Fast and straightforward installation without damaging the Load Cell, thanks to the SafeLock™ plates with integrated space for hydraulic jack

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	66,000 lb (30,000 kg)
Material	Zinc plated steel
Metrology	OIML C3, NTEP IIIL 10,000
Load Cell	0782/GD, 13 m cable
Accuracy	Standard
Protection Rating	IP68/69k
Environment / Material	Normal / Carbon Steel
Hazardous Approval	ATEX, FM
Criticality	Standard

Applications

Capacities for compression load cells, which are within compression weigh modules, range from 3 kg to 300 tons. Ideal for:

Large platform scales (truck and railroad track scales)
Tank, hopper and silo weighing systems
Industrial process weighing applications
